Full Assembly Hardware Set
All wires, cables, nuts, bolts, and structural fasteners.
System Overview
Designed as a field-class platform for autonomous operation, the TC-1 combines solar-to-thermal capture, directed airflow exchange, condensation recovery, and stored output buffering into a single deployable system.
Included Components
Multi-Stage Air Piping System
- Modular “Pipelets” (5 ft each)
- Configurable length at time of order
- Minimum required distance to ThermaCube: 25 ft (raw earth embed)
Circular Solar Array
- Radial deployment configuration
- Integrated thermal capture alignment
ThermaSorb Heat Shield
- High-efficiency thermal absorption layer
- Solar-to-heat amplification surface
ThermaFresnel Disc
- Focused solar intensification
- Directed thermal input to Core
ThermaCube™ Core Unit
- Central thermal mass and exchange structure
- Sealed chamber with controlled airflow routing
Energy Relay System + Inverters
- Power conditioning and distribution
- Grid-ready / off-grid compatible
Solid-State Battery Bank
- Capacity: 500 aH
- Rated for ~7 days uninterrupted operation
VerTurbines (x4)
- Vertical airflow-driven generators
- Integrated into channel network
Water Condensation Chamber
Atmospheric moisture extraction.
Filtration Substation
- Multi-stage purification
- Output-ready water supply
Deployment Class
Prototype / deployable field unit architecture for industrial and autonomous operation.
Core System Architecture
Solar Capture
→
Thermal Core
→
Airflow Channels
↓
Cold Sink Zone
↓
Condensation + Energy Recovery
Operating Notes
- System performance scales with pipelet length and burial depth.
- Optimal installation requires undisturbed soil for thermal stability.
- Circular solar array must maintain full sun exposure.
